A. Safety of IPL Any people who are eligible in using and maintaining can safely use this machine . Any operators and his/her assistants must know well the following safe notices and make sure both the operator and the customers are safe during the treatments . a) The machine will start inspection automatically after it is on.
b) Adopt the close filter /crystal of transferring light, the IPL can only emit from the front face
c) Independent electrical circuit, it will automatically stop working if the energy is too high.
d) The emergency switch is convenient when you are in emergency
e) The key switch can protect it from stolen because they can't start the machine without certain key B.Any intensive light without correct using will hurt people. It can work out high voltage when working;we suggest anybody who operates this machine should read this safety notices before using it. For Operator: it’s possible to touch the intensive light. So make sure you wear the 3 grade glasses. For customer: it is better if the operator is trained eligible and arrange a proper treatment room for the customer. It is even better if the customer knows the treatment theory and cooperates with the operator during the treatment. He/she must make sure wear the professional protective eye patch which protects his/her eyes from burning. About the treatment room: there must be clear mark which shows “using intensive light NOW!” 1)
【MAIN WARNING】 Please make sure you will carefully read the following warning tips: a) We need to warn you that it has dangerous high voltage .Anybody except technicians that authorized by our company can repair this machine. Especially the inside of device e.g.: electrical source,cooling system, optic organs and treatment head. etc. b) Make sure the voltage of this machine is same with yours, (110V or 220V) c) It will hurt both you and the machine if you repair it when it is still working, we strongly warn you that you must turn off the machine and pull out the electricity line and then start repairing it.
d) Keep the probe clean. MAKE SURE there is no cooling gel inside the probe.
e) Stop using the machine when the headpiece is leaking water, if it is already on, please close it immediately. 2)【WARNING ON INTENSIVE LIGHT】 a) The intensive light is possible to hurt your eyes or cause fire and burnt .so we suggest you wear the glasses. b) It will hurt the customer if you use too high energy or make too many shots in one 4 certain treatment area c) Do not directly see the intensive light or laser light even if you wear the protective glasses and eye patch. d) Do not point the treatment head to the air. Point it to the treatment area when using and hang it on the bracket when you don't use it. C. Safety of the electricity and equipment a) Keep all the panels and cover board closed. b) There is high voltage inside the machine even when it is off. So it is better not open the equipment if there is no need. c) Please make sure the electricity is off if you want to repair the machine d)this machine is about 45kg in net weight .it might hurt people if you move it in not proper ways. So pls make sure you move it slowly and carefully e) Safe power line designed with 3 cores. 1) a) The temperature of objects will rise after absorbing light energy, so please take actions to reduce the inflammable risk on treatment areas and surrounding areas. b) Do not use alcohol, acetone or other inflammable things on skin before treatment. You can just wash the skin with water or sometimes a little soap. c) If you use alcohol to disinfect the treatment head or any other parts, please wait till dry and then start the machine, otherwise it is dangerous. 2)【SYSTEM SAFETY SETTINGS】 a) Everybody in the operation room must know where the safety sets are and how to use them. b) Anybody who doesn't have our key is not able to start the machine. c) There is a red indicator light which will be on if you start the machine. d) Emergency button: the red switch is used to switch off power when you come to any emergency.Just press it and the machine will stop working .next time you use the machine, you need to turn this emergency button on. 3)【AUTOMATICAL INSPECTION】 It will start inspecting itself automatically when you start the machine. You need to turn on and turn off the machine repeatedly for 3 times and then start using it. 4)【LEVEL OF EQUIPMENT】 a) Level of motor protection: 1 CLASS, BF CLASS b) Anti‐corrosive liquid: general c) Not allowed to use this machine in room that exists inflammable anesthetic and nitrous oxide. d) Operation manner: continuous operation 5 II. E-light Part 1. Theory E-light takes strong pulse IPL and bipolar radio frequency electromagnetic wave with special width-spectrum, selectively acts on target texture, to do skin rejuvenation, freckle removal, hair removal, wrinkle removal effectively. On treatment if 5 to 10 times than traditional photon therapy. 1.1. Bipolar RF + IPL + Epidermis refrigeration: E-LIGHT combines good traits of IPL and Radio Frequency, warms up strong pulse, takes bipolar rf to strengthen acting on deep tissue, uses skin can selectively inhale light energy, to induce different impedance between target texture and normal skin. Under the circumstance of low light energy, it strengthens target texture to inhail radio frequency, greatly eliminate side effect like bleb, pigmentation caused by heat action of light energy filtering. E-light can penetrate skin deep, selectively act on hypodermal pigment, blood vessel, dissolve freckle, close abnormal vein, solve skins all kinds of flaws. Simultaneously, E-light can stimulator hypodermal collagen rebirth, make skin youth, health and smooth. 1.2. Specially Under precondition of precooling, energy will directly push into skin deep, epidermal pigmentation cannot inhail energy, so it can safely act on pigmented skin. Energy can enter15mm under skin. Light energy mainly uses on adjusting target texture impedance, avoid energy echo and reflection problem. Effectively act on any colored pathological changes, like target texture with similar as skin color. Surpass traditional laser and strong pulse therapy, E-light can completely solve many problems like skin rejuvenation, hair removal, acne skin etc. No matter what type of skin or hair color, all can get safe and effective therapy. 1.3. Applicable range : 1.3-1. Wrinkle removal, facelift, skin lift. Theory: It combines E-light (IPL and RF) technique, that is also said electromagnetic wave and IPL heat energy, to increase dermis layer temperature, stimulate collagen fibre rebirth and rearrangement, so as to do wrinkle removal, face lift and lift skin without pain. Safety: Cause it mainly uses RF energy to penetrate hypodermal 15MM, acts on dermis layer, and very low influence on epidermis, collects main energy on target texture, so-called very safe. 1.3-2. Permanent hair removal. 6 IPL hair removal theory: It uses light with selective inhalation, through hair nipple of hair trunk and hair folliculus, which exists rich melanin cell, to inhale strong pulse IPL, produce heat energy into hair folliculus, folliculus temperature will be rapidly increased and the foliculus will be putrescence, so that can effective remove hair for ever. IPL and RF together to do hair removal: Based on IPL technique, it combines radio frequency energy which can down to hypodermal 15MM, directly acts on hair folliculus, make their melanin inhale more energy, so that has better effect on tiny thin hair, light hair, golden hair and white hair. Safety: It simply uses IPL hair removal equipment, very safety on light skin, thick and black hair., but uses IPL and RF together, will also very safety on all colored skin and hair, and more effective on hairs around the lip, golden hair and white hair.
1.3-3. Dispel deep freckle, epidermis freckle, whiten skin, dispel thread vein. Simple IPL technique: it uses Hemoglobin and pigment group which can inhale light selectively and dissolve, to increase target texture temperature. Under the premise not to damage normal skin tissue especially epidermis, make target texture, putrescence, so as to get good therapy.
1.3-4. Acne skin therapy The before IPL equipment, it doesn’t have effective therapy on acne skin, but now, we uses IPL and RF technique together, get very good result in clinic. Theory: It uses IPL and RF energy, act on and kill Ciprofloxacin bacilli existed in acne, decrease sebaceous gland activation, at same time, it will elimite pigmentation, stimulate deep collagen rebirth and rearrangement, so as to get good result. Safety: Cause it uses IPL and RF complex energy, it can act on different deep layer, not single energy, so it can make sure more safety and effective on curing.
2. Functions We know E-light machine is good at removing thick black hair, but it can't remove thin light hair .e.g.: lip hair,Intensive pulse light works on the hair which absorbs the light and transfer it to heat and transport it to hair follicle and then destroy it . But if it is thin light hair .the energy that it can absorb is not high enough to destroy its hair follicle .so we develop E light system to solve this problem. E light's RF energy can directly work on hair follicle that is 15nm under derma .so it is also good at thin light hair removal . Standard:
1) Hair removal (640nm~1200nm) 2) pigment & wrinkle removal (530nm~1200nm) 7 3)Skin rejuvenation & Vascular (480nm~1200nm) Optional:(430nm,560nm,590nm,690nm) Note：this machine only one handle,so you can choosing the filter. 3. Course of treatment Item Period of treatment(PT) Remark requirements Hair removal 1 time every 21-40days, 3-6 times every PT. Shaving the unwanted hair at the treatment area Freckle removal 1 time every 21-28days, 6 times every PT. 1. The patients should be suitable to accept treatment. It means they don’t have the symptom described in Contraindications 2. No hypersusceptibility recently 3. The patients should cooperate with operator’s instructions 4. Clean treatment area after treatment Skin rejuvenation 1 time every 21-28days, 6 times every PT. Vascular therapy 1 time every 21-28days, 3-6 times every PT. Acne skin 1 time every 21-28days, 3-6 times every PT. Lifting 1 time every 21-28days, 6 times every PT. Remarks: Parameters should be adjusted according different person, professional beautician should keep asking the feeling of the client and adjust parameters according the actual status. 4. Installation 1)【Components of the device】 ◆
Assembly parts Power line Water pipe Water funnel Professional protective glasses Professional protective eye patch
